T8 LED 8 Foot (NO RF) 144w Fa8 Single Pin FROSTED LENS 17,654 Lumen! Quad-Row

Regular price

As Low As: $15.58
$15.58

SPECIFICATION SHEET

NO RF SERIES -- This product has a RF filtering system within the driver in each unit.  RF interference is a fairly common problem in high output linear lighting, due to "RF Noise" in the AC line feeding the light.  This problem creates "static" in radio reception as well as garage opener remote control performance issue.

This is our newest High Output Retrofit Series product.  This model features a Quad-Row LED configuration using 144 watts for and astounding 17,654 lumens of throw at 170 degrees.

Great for 14-18' ceilings or where you want a LOT of light

 - - These lights are very bright and are not recommended for low mounting heights

- Instant On in cold conditions, like coolers, meat prep, garages, pole barns, etc.

- The New innovative design includes Fa8 Single Pin Mount and Quad-Row 170 Degree Projection.  Looks and performs as a high end, Commercial/Industrial LED product should.  Use in work shops, utility sheds, utility and laundry rooms, etc.

- Our Quad-Row Series lights provide excellent lumen projection, using few watts, and are designed to replace inefficient High Output fluorescent/magnetic ballast systems using multiple lamps.

- Easy to install, offering Fa8 Single Pin, AC Direct Wire Ballast By-Pass Installation.

Specifications:
T8 8' Fa8 Single Pin
144 Watt
Cree LED's
17,654 Lumens FROSTED LENS
CLEAR COVER
85-265V Grounded Driver
122 Lumens Per Watt - High Efficacy System with Superior Driver Technology
5500-6000K White is standard, other Kelvin may be available by special order
Certification: UL Listed
Industrial/Commercial Grade
Interlinking for continuous runs of up to 3 units
85+ CRI
Instant Start In Cold Conditions
No Flicker or Hum
Aluminum/Polycarbonate Construction
12 Year Simple Exchange Warranty based on LM79 Rated 80,000 Hours



DRIVER SPECIFICATIONS

WARRANTY STATEMENT

WIRE COLOR CODE FOR INSTALLATION
