5 Foot R17d 56 Watt CLEAR LENS 7.296 Lumens

NEW !!

 6' R17d Swivel Ends Replacement Lamp (measures 57.91 inches tip to tip)

2 rows of LED's mounted on a 270° V-Pattern, so when mounted on the door rail of reach-in coolers in place of fluorescent lamps, the light will throw to the left and right to light the product much better than fluorescent systems, at a much lower energy cost.

Each lamp uses existing R17d Tombstone's and the ends swivel, so they are adjustable to any brand of R17d Tombstone (Socket)

Direct Wire Ballast By-Pass, 2 end AC hookup, just power one socket to Black (Hot) and the other to White (Neutral) - no more ballast issues or energy consumption

- Instant On in cold conditions, like coolers, meat prep, garages, pole barns, etc.

- Looks and performs as a high end, Commercial/Industrial LED product should.  Use in Reach-In Coolers, work shops, utility sheds, utility and laundry rooms, etc.

- Our Dual-Row V-Series lights provide excellent 270 degree Lumen Projection, using few watts, and are designed to replace inefficient High Output fluorescent/magnetic ballast systems.

- Easy to install R17d Dual-Contact Pin mount, Direct Wire Ballast By-Pass installation.

Specifications:
T8 5 Foot R17d Pin Mount SWIVEL ENDS
48 Watt
Ballast By-Pass, 2 End AC Installation (See Picture)
Cree LED's
7,296 Lumens Clear Cover
CLEAR COVER
85-277V Driver
152 Lumens Per Watt - High Efficacy System with Superior Driver Technology
5500-6000K White is standard, other Kelvin may be available by special order
Certification: UL CE FCC
Industrial/Commercial Grade
150 watt Fluorescent Equivalent
85+ CRI
Instant Start In Cold Conditions
No Flicker or Hum
Aluminum/Polycarbonate Construction
12 Year Warranty based on LM79 Rated 80,000 Hours



DRIVER SPECIFICATIONS

WARRANTY STATEMENT

WIRE COLOR CODE FOR INSTALLATION
